Milesight UG67 – Outdoor LoRaWAN Gateway
Overview
Gateway LoRaWAN untuk pemasangan luar ruangan dengan IP67 dan suhu kerja -40 °C sampai +70 °C. Mendukung hingga 2.000 perangkat, jangkauan sampai 15 km di area terbuka, dan menyalurkan data ke BMS lewat BACnet atau Modbus.
Fitur Utama
- IP67 dan -40 °C sampai +70 °C untuk cuaca ekstrem
- 8 kanal full-duplex dengan Semtech SX1302 dan LoRaWAN Class A/B/C
- Hingga 2.000 perangkat : jangkauan 15 km di area terbuka, 2 km di area urban
- Backhaul ganda : Ethernet (PoE), Wi-Fi, dan 4G LTE dengan failover
- Superkapasitor dengan cadangan 1 menit untuk peringatan mati listrik
- GNSS tertanam (GPS/GLONASS/QZSS/SBAS)
- Integrasi BMS lewat BACnet/IP, BACnet/SC, Modbus TCP, dan MQTT
- Listen Before Talk dan Noise Analyzer
Sederhananya: perangkat ini cocok untuk area luar gedung, atap, parkir, dan kawasan yang luas yang butuh jangkauan sensor nirkabel tanpa menarik kabel.
Penerapan
Dipakai di mana, dan apa spesifikasinya.
Sistem
Application
Deskripsi
Tentang produk ini.
| Specification | Value |
|---|---|
| Hardware System | |
| CPU | Quad-core 1.5 GHz, 64-bit ARM Cortex-A53 |
| Memory | 512 MB DDR4 RAM |
| Flash | 8 GB eMMC |
| LoRaWAN | |
| Antenna Connector | 2 × 50 Ω N-female external connectors |
| Channel | 8 (half/full-duplex) |
| Frequency Band | CN470/IN865/RU864/EU868/US915/AU915/KR920/AS923-1&2&3&4 |
| Sensitivity | -140 dBm @292bps |
| Tx Power | 27 dBm max |
| LBT | Supported (not for AU915/US915) |
| Protocol | V1.0 and V1.0.2 Class A/B/C |
| Network Interfaces | |
| Ethernet | 1 × RJ45 WAN port (PoE PD supported); 10/100/1000 Mbps; isolation 1.5 kV RMS |
| Wi-Fi | IEEE 802.11 b/g/n, 2.4 GHz; internal antenna |
| Cellular | 4G LTE; internal antenna; 1 × mini SIM (2FF) |
| GNSS | GPS/GLONASS/QZSS/SBAS; internal antenna |
| Software | |
| Integration | MQTT(S), HTTP(S), BACnet/IP, BACnet/SC, Modbus TCP, Modbus RTU over TCP |
| Network Protocols | PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, DDNS, HTTP, HTTPS, DNS, ARP, SNTP, Telnet, SSH, etc. |
| VPN Tunnel | OpenVPN, IPsec, PPTP, L2TP, GRE, DMVPN, WireGuard |
| Management | Web, CLI (SSH/Telnet), SMS, SNMP, HTTP API, MQTT API, Milesight Development Platform, DeviceHub |
| Power & Physical | |
| Power Supply | 802.3af PoE, or 6–12 VDC via M12 connector |
| Power Consumption | Typical 3.6 W, max 4.8 W |
| Ingress Protection | IP67 |
| Weight | 1463 g |
| Dimension | 240 × 164 × 90.9 mm |
| Installation | Wall or pole mounting |
| Operating Temperature | -40 °C to +70 °C (reduced cellular performance above 60 °C) |
| Relative Humidity | 0% to 95% (non-condensing) at 25 °C |
| Approvals | CE, FCC, TELEC, CE (RED), RoHS |
